With a half-width rackmount design, a QSW-3216R-8S8T can be installed in a 1U rack space with another half-width rackmount switch (such as QSW-M3216R-8S8T) for efficient physical space utilization and tidy cabling.
Note: The optional SP-EAR-QSW2FOR1-01 rackmount kit is required if two half-width rackmount switches are installed.
The QSW-3216R-8S8T provides eight 10GbE SFP+ ports and eight 10GbE RJ45 ports for connecting various devices and enabling high-speed networks. With SFP+ interfaces, Direct Attach Copper (DAC) cables can be used for connecting directly to SFP+ devices. You can also use RJ45 ports to connect 10GBASE-T/NBASE-T™ devices through RJ45 Category 6 (or better) cabling.
Note: 10GbE SFP+ ports are backward compatible with 1GbE SFP; the 10GbE RJ45 ports support up to five speeds (10G/5G/2.5G/1G/100M).
No complex settings are required to use the QSW-3216R-8S8T - simply connect your devices with existing cables and it’s ready to use. The QSW-3216R-8S8T supports auto-negotiation that optimizes transfer speeds (10G/5G/2.5G/1G/100M) and performance for each connected device.
The QSW-3216R-8S8T features network loop detection. If a network loop is detected, the QSW-3216R-8S8T automatically locks the looped ports to ensure the network environment quickly resumes normal operation.
With a compact metal body that optimizes cooling performance, the QSW-3216R-8S8T provides stable and reliable operations even when under full load. The front-panel LEDs also assist in viewing the current system status.
QNAP offers comprehensive, budget-friendly storage and networking solutions that provide an array of connectivity possibilities. Easily and flexibly upgrade your workplace or home network now to handle bandwidth-hungry applications.
QNAP 2.5GbE/10GbE switches support 10G/5G/2.5G/1G/100M and allow connecting multiple workstations and devices for high-speed collaboration in device-dense environments.
QNAP provides comprehensive enterprise managed and unmanaged switches with speeds ranging from 2.5GbE, 10GbE to 25GbE and covering PoE, industrial-grade, rackmount, and desktop models. QNAP’s all-inclusive high-speed switches assist businesses in quickly deploying high-speed network infrastructure, accelerating enterprise backbone, smart hotels, retail, and industry 5.0 applications.
Manufacturer Warranty: 2 Years Manufacturer Warranty
|Number of Ports
|10GbE BASE-T (RJ45)
|Power Supply Description
|Internal Power supply Unit
|Max. Power Consumption
|Input Power Type
|Input Voltage Range
|MAC Address Table
|Total Non-Blocking Throughput
|PWM VAPO Bearing fan x 2
|IEEE 802.3 Ethernet
IEEE 802.3u 100BASE-T
IEEE 802.3ab 1000BASE-T
IEEE 802.3z 1000BASE-SX/LX
IEEE 802.3ae 10G Fiber
IEEE 802.3x Full-Duplex Flow Control
|Per Port: Speed/Link/Activity
Per System: Power/Status
|43.3 x 207 x 199.5 mm
|0˚C to 40°C (32°F to 104°F)
|CE, FCC, VCCI, BSMI
